Asrock B860M-H2 (LGA 1851) DDR5 Micro-ATX Motherboard, Intel Core Ultra compatible, LGA 1851 Socket, B860, PCIe Gen 5, Micro-ATX, 2x DIMM slots, DDR5, 2 x M.2 , 4 x SATA, 1Gb LAN, Type-C

The ASRock B860M-H2 is a Micro-ATX motherboard designed for Intel's 14th and 13th Gen Core Ultra processors, featuring the LGA 1851 socket. It offers a balance between performance and affordability, making it suitable for users seeking reliable computing capabilities.

Key Specifications

• Socket: LGA 1851
• Chipset: Intel B860
• Form Factor: Micro-ATX (9.6" x 8.3")
• Memory:
• 2× DDR5 DIMM slots
• Supports up to 128GB
• Native speeds up to 6400 MHz
• Overclocking up to 8333+ MHz (1DPC 1R)
• Expansion Slots:
• 1× PCIe 4.0 x16
• 2× PCIe 4.0 x1
• Storage:
• 1× M.2 PCIe Gen5 x4
• 1× M.2 PCIe Gen4 x4
• 4× SATA III 6Gb/s
• Networking:
• 1× 1Gb Ethernet (Realtek 8111H)
• No built-in Wi-Fi
• USB Ports:
• 1× USB 3.2 Gen2x2 Type-C (rear)
• 1× USB 3.2 Gen1 Type-C (front header)
• 5× USB 3.2 Gen1 Type-A (3 rear, 2 front)
• 6× USB 2.0 (2 rear, 4 front)
• Graphics Outputs:
• 2× HDMI 2.1
• Audio:
• Realtek ALC897 codec
• 7.1-channel HD audio
• Cooling:
• 1× CPU fan header
• 2× chassis fan headers
• 1× AIO pump header
• Power Connectors:
• 1× 24-pin ATX
• 1× 8-pin 12V
• BIOS:
• Flashback support
• ASRock EZ Mode and Full HD UEFI
• Certifications:
• Microsoft Windows 11 64-bit
• FCC, CE, ErP/EuP ready
