Asus
Asus Radeon RX 6500 XT Dual OC 4G V2 Graphics Card (DUAL-RX6500XT-O4G-V2)
Description
The ASUS Radeon RX 6500 XT Dual OC 4G V2 (model DUAL-RX6500XT-O4G-V2) is a compact and efficient graphics card designed for 1080p gaming and general-purpose computing. It leverages AMD's RDNA 2 architecture to deliver solid performance in a small form factor.
Key Specifications
- GPU Engine: Radeon RX 6500 XT
- Stream Processors: 1,024
- Memory: 4GB GDDR6
- Memory Interface: 64-bit
- Memory Speed: 18 Gbps
- Boost Clock: Up to 2,820 MHz
- Game Clock: Up to 2,670 MHz
- Interface: PCIe 4.0
- Outputs: 1 × HDMI 2.1, 1 × DisplayPort 1.4a
- Max Resolution: 7680 x 4320
- Power Connectors: 1 × 6-pin
- Recommended PSU: 500W
- Dimensions: 201 × 128 × 40 mm
- Cooling: Dual Axial-tech fans with dual ball bearings
- Slot Size: 2-slot
Cooling & Build Quality
The V2 model retains the compact 2-slot design of its predecessor but upgrades the cooling system. It features an aluminum fin-stack heatsink with a direct-contact heatpipe, enhancing thermal performance. The dual Axial-tech fans are designed for increased airflow and durability, with dual ball bearings that last up to twice as long as sleeve bearings. Additionally, the card includes a protective backplate to prevent PCB flex and trace damage.
Performance & Features
Built on the 6 nm "Navi 24" silicon, the RX 6500 XT incorporates all 1,024 stream processors available on the chip. The factory overclocked speeds of 2,820 MHz (boost) and 2,670 MHz (game) provide a performance edge over the reference specifications. The card supports AMD FidelityFX Super Resolution (FSR) technology, which can boost frame rates by an average of 2.4X across select supported games.
deal Use Cases
This graphics card is well-suited for:
- 1080p gaming at high settings
- Compact PC builds with limited space
- Users seeking efficient performance without excessive power consumption
