Features :
1.Auto Negotiation of speed and duplex modes
2.802.3x Flow Control
3.DHCP Client
4.Dynamic MAC address management
5.IEEE 802.1Q-based or port-based VLAN
6.QoS based on WRR, strict priority, or both
7.Port-based and IEEE 802.1p-based QoS
8.QoS based on ToS (Type-of-Service)
9.DSCP Support (GS105E and GS105PE only)
10.Rate Limiting
11.IGMP snooping, v1, v2 and v3
12.Blocking of unknown multicast traffic
13.Act as static multicast router port
14.Port mirroring both on ingress and egress traffic
15.Jumbo frame support
Technical Specs :
Product Number : GS108PE
Gigabit Ports : 8
10 Gbps Port : n/a
Number of PoE ports : 4
Total PoE Power budget (Watts) : 53
Max MAC entries : 4K
Buffer size : 192KB
VLAN (Number Supported) : 32
Number of LAGs & number of members : n/a
Supported Mulitcast groups : 128
Max number of source ports allowed (many to 1) : 7
Internal/External : External, Input: 48V/1.25A
Max consumption (Watts) : 7.0W (no PoE) / 60.0W (w/PoE max)
FAN : No
Acoustic Noise Level @25C (dBA) : 0
Operating Temperature : 0° to 50° C
MTBF (hrs) : 1,242,394 hrs
Weight (kg) : 0.54Kg
Dimensions (WxDxH) mm : 158x101x29
Electromagnetic Compliance (A or B) : A
Control and Configure Beyond Plug-N-Play Connectivity :
Today’s growing businesses demand and rely more on their network to carry out mission-critical business activities. Companies are putting more network traffic and applications such as VoIP phones and IP cameras on their Ethernet infrastructure. It needs the network intelligence to separate the voice and video traffic from data, and prioritize them accordingly. However, companies do not necessarily have more money or advanced training to deal with complex managed switches. NETGEAR Smart Managed Plus Switches meet this growing need by providing fundamental network features that will help optimize the performance of business networks. On top of the plug-N-play Gigabit Ethernet connectivity, these switches also offer essential networking features such as VLAN, QoS, IGMP Snooping, Link Aggregation / Port Trunking on models with 16 ports or more, rate limiting and traffic monitoring. NETGEAR Smart Managed Plus Switches are an exceptional value for businesses looking to add intelligence to their network beyond what unmanaged switches can provide.
Prioritize Voice/Video :
With the ability to set up and configure QoS, these Gigabit Smart Managed Plus Switches can detect different types of network traffic and assign the desired priority to latency-sensitive traffic, such as voice and video. This helps improve the delivery quality of related applications such as VoIP, multimedia broadcasting, and video conferencing.
Build Multiple Network Groups :
These Gigabit Smart Managed Plus Switches can help divide big networks into smaller more manageable groups and have resources dedicated for one or several groups rather than making the same resources open to all. This feature improves overall network performance, adds security to network traffic, and makes more efficient use of network resources.
